ServerWare® Solutions
– Reference Architectures, Fully Integrated Systems and Rack Installed Solutions

ServerWare® Total Solutions are  collaborated, designed and optimized to address our customer’s leading IT challenges and opportunities. Open industry standards based architectures built from Supermicro’s exhaustive product portfolio enable the right choice of form-factor, RAS features, efficiency and manageability for the targeted workload. The solutions are designed to help customers reduce IT Project complexity and risk, control acquisition and operational costs and accelerate time to market.

Every Solutions Works Specifically As it is Designed



ServerWare®, in collaboration with Supermicro’s Virtual SAN (VSAN) Ready Nodes focus on deploying VMware® Virtual SAN™, a hypervisor converged solution, as quickly as possible. Virtual SAN provides you with the ability to provision and manage compute, network and storage resources from a single pane of management. Working with VMware, Supermicro delivers an alternative to traditional Fiber Channel SAN based virtualization infrastructure, which is known for its complexity and interoperability challenges. Targeted at a multitude of use cases in tier 1/2 production workloads and Virtualized Desktop Infrastructure (VDI), especially with all flash VSAN 6.2, Supermicro’s VSAN Ready Nodes introduce a new high performance storage tier optimized for enterprise-class virtual environments that is simple, resilient and efficient that reduces the total cost of ownership. It is a perfect solution for Enterprises ROBO and SMBs to efficiently grow and manage virtualized infrastructure for maximum ROI.
A Virtual SAN Ready Node is a preconfigured single-node or multi-node server hardware configuration for use with Virtual SAN. A Ready Node configuration includes specific type and amount of CPU, Memory, Flash, HDD, and IO Controller devices within each server. Each VSAN Ready Node is classified by a Ready Node configuration profile. Defined Ready Node profiles include:

Serverware® is Supermicro® distributor, Server, Storages, Solutions



Serverware® is Supermicro® distributor, Server, Storages, Solutions

• Hybrid Ready Node Profiles*
– HY-8 Series: Up to 100 VMs per node
– HY-6 Series: Up to 50 VMs per node
– HY-4 Series: Up to 30 VMs per node
– HY-2 Series: Up to 20 VMs per node
• All-Flash Ready Node Profiles*
– AF-8 Series: Up to 120 VMs per node
– AF-6 Series: Up to 60 VMs per node
– AF-4 Series: Up to 30 VMs per node


Each configuration profile provides a differentiated price/performance focus, targeting multiple use case requirements. Each profile assumes a target number of Virtual Machines per node, utilizing an average Virtual Machine profile size. Fault tolerance is built into the solution with data replication between nodes, and clustering technology. Flash and hard disks are seamlessly integrated to achieve best balance in performance and capacity.
*For more information about Virtual SAN Ready Node profiles and VM sizing assumptions, refer to VMware’s Virtual SAN Hardware Quick Reference Guide


Benefits
Single bundle for procurement – Supermicro VSAN Ready Node comes with the appropriate licenses for vSphere and Virtual SAN. Supermicro production and service works with customer to simplify the setup experience.
Radically Simple Storage – VSAN integrates seamlessly with vSphere platform for storage tasks. Storage provisioning and management is a breeze. VSAN automatically rebuilds and rebalances storage to maintain Quality of Service from the storage resource.
Lower TCO by up to 50% – VSAN allows you to granularly scale-out you storage environment to allow for growth while eliminating overprovisioning.
High Performance – VSAN has integrated server-side flash to provide read/write caching, providing lower latency and better throughput than external flash appliances and devices. As a result, VMs and applications have the most optimized I/O data path to support your business demands.
Fault Tolerance – VSAN uses distributed RAID and cache mirroring to ensure that data is never lost in case of disk, host or network failures. Combined with Supermicro’s legendary quality and reliability aids in enhancing system uptime and ensuring business continuity.
Peace of Mind – Supermicro VSAN Ready Nodes are jointly recommended with VMware. Full system delivery ensures compatibility and maximizes the success of implementation.


Virtual SAN Ready System

All-Flash Supermicro Virtual SAN Ready Nodes
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-8 (All-Flash)
21TB Raw Capacity
Serverware® is Supermicro® distributor, Server, Storages, Solutions
SYS-2028U-VSMC11C / SYS-2028U-VSMC12C
SYS-2028U-VSMH11C* / SYS-2028U-VSMH12C*
2U Single VSAN Ready Node based on AF-8 Ready Node Profile
21 TB Raw Capacity (21x 960 GB SSDs, 3x 600GB Caching SSDs)
28 Cores (2x Intel Xeon E5-2690 v4)
512 GB Memory (16x 32GB DDR4-2400)
3 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (11C models) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (12C models)
Micron SOLID Ready
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-6 (All-Flash)
12TB Raw Capacity|
Serverware® is Supermicro® distributor, Server, Storages, Solutions
SYS-2028U-VSMC11B / SYS-2028U-VSMC12B
SYS-2028U-VSMH11B* / SYS-2028U-VSMH12B*
2U Single VSAN Ready Node based on AF-6 Ready Node Profile
12 TB Raw Capacity (12x 960 GB SSDs, 2x 600GB Caching SSDs)
24 Cores (2x Intel Xeon E5-2650 v4)
256 GB Memory (16x 16GB DDR4-2400)
4 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (11B models) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (12B models)
Micron SOLID Ready
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-4 (All-Flash)
8TB Raw Capacity
Serverware® is Supermicro® distributor, Server, Storages, Solutions
SYS-2028U-VSMC11A / SYS-2028U-VSMC12A
SYS-2028U-VSMH11A* / SYS-2028U-VSMH12A*
2U Single VSAN Ready Node based on AF-4 Ready Node Profile
8 TB Raw Capacity (8x 960 GB SSDs, 2x 600GB Caching SSDs)
24 Cores (2x Intel Xeon E5-2650 v4)
256 GB Memory (16x 16GB DDR4-2400)
4 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (11A models) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (12A models)
Micron SOLID Ready
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
* Models that do not include VMware vSphere & Virtual SAN

 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-8 (All-Flash)
14.4TB Raw Capacity
 SYS-2028U-VSNF11L / SYS-2028U-VSNF12L
2U Single VSAN Ready Node based on AF-8 Ready Node Profile
14.4 TB Raw Capacity (12x 1.2 TB SSDs, 2x 800GB Caching SSDs)
24 Cores (2x Intel Xeon E5-2680 v3)
384 GB Memory (24x 16GB DDR4)
4 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (VSNF11L) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (VSNF12L)
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-6 (All-Flash)
8TB Raw Capacity per node
 SYS-2028TP-VSNF11X / SYS-2028TP-VSNF12X
2U Four VSAN Ready Nodes based on AF-6 Ready Node Profile
8 TB Raw Capacity (2x 4 TB SSDs, 1x 400GB Caching SSD)
24 Cores (2x Intel Xeon E5-2670 v3)
256 GB Memory (16x 16GB DDR4)
Dual 1GbE + Dual 10GbE R45 (VSNF11X) OR Dual 1GbE + Dual 10GbE SFP+ (VSNF12X)
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-6 (All-Flash)
8TB Raw Capacity per node
 SYS-2028TP-VSNF11M / SYS-2028TP-VSNF12M
2U Four VSAN Ready Nodes based on AF-6 Ready Node Profile
8 TB Raw Capacity (5x 1.6 TB SSDs, 1x 800GB Caching SSD)
24 Cores (2x Intel Xeon E5-2670 v3)
256 GB Memory (16x 16GB DDR4)
Dual 1GbE + Dual 10GbE R45 (VSNF11M) OR Dual 1GbE + Dual 10GbE SFP+ (VSNF12M)
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
AF-4 (All-Flash)
4TB Raw Capacity per node
 SYS-2028TP-VSNF11E / SYS-2028TP-VSNF12E
2U Four VSAN Ready Nodes based on AF-4 Ready Node Profile
4 TB Raw Capacity (5x 800 GB SSDs, 1x 200GB Caching SSD)
20 Cores (2x Intel Xeon E5-2650 v3)
128 GB Memory (8x 16GB DDR4)
Dual 1GbE + Dual 10GbE R45 (VSNF11E) OR Dual 1GbE + Dual 10GbE SFP+ (VSNF12E)
VMware vSphere 6 Standard & Virtual SAN 6.2 Advanced with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
Hybrid Supermicro Virtual SAN Ready Nodes
Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-8 (Hybrid)
24TB Raw Capacity
 SYS-2028U-VSN011X / SYS-2028U-VSN012X
2U Single VSAN Ready Node based on HY-8 Ready Node Profile
24 TB Raw Capacity (20x 1.2 TB HDDs, 4x 400GB Caching SSDs)
24 Cores (2x Intel Xeon E5-2680v3)
384 GB Memory (24x 16 GB DDR4)
5 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (VSN011X) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (VSN012X)
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-8 (Hybrid)
14.4TB Raw Capacity
SYS-2028U-VSN011L / SYS-2028U-VSN012L
2U Single VSAN Ready Node based on HY-8 Ready Node Profile
14.4 TB Raw Capacity (12x 1.2 TB HDDs, 2x 800GB Caching SSDs)
24 Cores (2x Intel Xeon E5-2680v3)
384 GB Memory (24x 16 GB DDR4)
4 PCI-E 3.0 x8 Expansion Slots
Quad 10GbE R45 (VSN011L) OR Dual 10GbE RJ45 + Dual 10GbE SFP+ (VSN012L)
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-8 (Hybrid)
9.6TB Raw Capacity
Serverware® is Supermicro® distributor, Server, Storages, Solutions
SYS-1028U-VSN011N / SYS-1028U-VSN012N
1U Single VSAN Ready Node based on HY-8 Ready Node Profile
9.6 TB Raw Capacity per node (8x 1.2 TB HDDs, 2x 400GB Caching NVMe SSDs)
24 Cores (2x Intel Xeon E5-2680v3)
256 GB Memory (8x 16 GB DDR4)
2 PCI-E 3.0 x16 Expansion Slots
Quad 10GbE (VSN011E) OR Dual 10GbE + Dual 10GbE SFP+ (VSN012E)
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-6 (Hybrid)
6TB Raw Capacity per node
 SYS-2028TP-VSN011M / SYS-2028TP-VSN012M
2U Four VSAN Ready Nodes based on HY-6 Ready Node Profile
6 TB Raw Capacity (5x 1.2 TB HDDs, 1x 800GB Caching SSD)
24 Cores (2x Intel Xeon E5-2670v3)
256 GB Memory (16x 16 GB DDR4)
Dual 1GbE + Dual 10GbE R45 (VSN011M) OR Dual 1GbE + Dual 10GbE SFP+ (VSN012M)
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-4 (Hybrid)
4TB Raw Capacity
 SYS-1028U-VSN011E / SYS-1028U-VSN012E
1U Single VSAN Ready Node based on HY-4 Ready Node Profile
4 TB Raw Capacity per node (4x 1 TB HDDs, 1x 200GB Caching SSD)
20 Cores (2x Intel Xeon E5-2660v3)
128 GB Memory (8x 16 GB DDR4)
2 PCI-E 3.0 x16 Expansion Slots
Quad 1GbE + Dual 10GbE RJ45 (VSN011E) OR Quad 1GbE + Dual 10GbE SFP+ (VSN012E)
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
HY-2 (Hybrid)
5TB Raw Capacity
 SYS-1018R-VSN001S
1U Single VSAN Ready Node based on HY-2 Ready Node Profile
5 TB Raw Capacity (5x 1 TB HDDs, 1x 200GB Caching SSD)
6 Cores (1x Intel Xeon E5-2620v3)
64 GB Memory (4x 16 GB DDR4)
1 PCI-E 3.0 x8 LP Expansion Slot
6 1GbE ports
VMware vSphere 6 Standard & Virtual SAN 6.2 Standard with Production SnS for 3 Years
Supermicro 4-Hour Onsite Hardware Service for 3 Years (OS4HR3)
Other Virtual SAN components
 Serverware® is Supermicro® distributor, Server, Storages, Solutions 1Gb & 10Gb Ethernet Switches
Layer 2/3 Ethernet Switching, link aggregation (LACP), Jumbo frames, VLAN support
Configuration Flexibility:
SSE-G24-TG4 – 24 ports of RJ45 1Gbps Ethernet with 4 SFP Combo ports,
4 ports 10Gbps Ethernet (CX4, XFP, or SFP+), Stacking
SSE-G48-TG4 – 48 ports of RJ45 1Gbps Ethernet with 4 SFP Combo ports,
SSE-X3348T(R) – 48 ports of RJ45 10Gbps Ethernet
SSE-X24S / SSE-X3348S(R) – 48 ports 10Gbps Ethernet (SFP+), Reverse airflow option
Management: Web-based management interface, Industry standard CLI with telnet
SSH or local management port, Scripting, Logging
Routing, Multicast: Quality of service and DiffServ – 8 priority queues per port; Adjusted
WRR and Strict Priority Scheduling; Security – 802.1x port based authentication, RADIUS
and TACACS+ authentication, SSH / SSL encryption
Dimensions: 17.3″W x 15.2″D x 1.7″H (440mm x 386mm x 43mm)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions  IPMI Server Management
HW fault alerts – E-mail or SNMP
Redundant access for management
Support for open standards (SMASH 2.0, LDAP, WSMAN)
VLAN support
KVM and Virtual Media and SOL (no additional license needed)
Easy maintenance (Command line flash tools for firmware update)
 Serverware® is Supermicro® distributor, Server, Storages, Solutions
Serverware® is Supermicro® distributor, Server, Storages, Solutions
 VMware Cluster Management
VMware vCenter Server provides a centralized platform for managing the Supermicro VMware Virtual SAN solution. vCenter Server is required. Supermicro provides the full range of VMware vCenter products, as well as the server and OS to complete the whole environment. Contact your Supermicro Sales Representative for details of our VMware software offerings.


ServerWare®/Supermicro® Solutions for OpenStack
OpenStack is the proven Open Cloud Platform being adopted by Service Providers and Enterprise Private Clouds enabling large scale production-ready clouds that accelerate innovation and drive down the Total Cost of Ownership (TCO) for cloud solutions. Supermicro has partnered with the leading OpenStack software firms to jointly-engineer total solutions for OpenStack. These solutions are built on best-in-class Supermicro Server and Storage systems that deliver broad platform choice, fast to market innovation and optimized for value, performance and efficiency.

Serverware® is Supermicro® distributor, Server, Storages, Solutions



  1. Open, modular OpenStack solutions for cloud computing
  2. Accelerate and simplify deployment and reduce risk with jointly engineered and tested OpenStack reference architectures and converged system appliances
  3. Select from the broadest portfolio of server and storage systems to develop the optimal cloud architecture
  4. Leverage tested and proven reference architectures with your choice of OpenStack software and accelerate Cloud deployment with turn-key Cloud Converged Cloud Appliances with complete software, hardware and services


ServerWare®/Supermicro® Unlocked Appliance for Mirantis Supermicro and Mirantis are bringing the best of cloud and converged infrastructure together to simplify OpenStack® deployments and reduce the time-to-value of your private cloud, allowing you to focus on your business and your applications.





Start Learning »

Mirantis



ServerWare®/Supermicro®’s solutions for Red Hat leverage Red Hat Enterprise Linux OpenStack Platforms to offer a fully integrated, optimized foundation for building OpenStack cloud infrastructure with maximized performance, scalability and security.





Start Learning »

Redhat



ServerWare®/Supermicro® Software Defined Storage Solutions
The storage landscape is evolving from premium priced proprietary hardware and software solutions to open industry standard hardware and the benefits are significant: reduced vendor lock-in, significantly open innovation with new technologies like all NVMe solutions. Supermicro’s extensive storage platform of choice for leading storage vendors and major hyperscale datacenters.



Supermicro delivers significant benefits to Software Defined Storage Solutions:



Maximum Efficiency – High capacity 1U-4U form factors. Leading the industry with up 95% efficient Platinum level power supplies
Maximum Performance and expandability – All NVMe support with hybrid expander and delivering up to 20 GB/s throughput



Mission Critical Reliability – Capable of fully redundant and fault-tolerant operation with supplies, fans and redundant serverboards with remote management



Proven Compatibility – Lab validated hardware configurations optimized for high duty cycles workloads


ServerWare®/SuperStorage Ceph solutions offer validated platforms to enable cloud deployments that increase operational efficiency while maintaining control of physical resources. The hardware and software support cloud deployments need to increase operational efficiency while maintaining control of physical resources





Start Learning »

Serverware® is Supermicro® distributor, Server, Storages, Solutions



ServerWare®/Supermicro-Nexenta storage solutions are a series of optimized reference architectures (RA) based on Supermicro’s industry leading server hardware and Nexenta’s, innovative Software Defined Storage platform





Start Learning »

nexenta



ServerWare®/Supermicro’s VSAN Ready Systems have been created to focus on getting a simple hypervisor-converged storage cluster up and running as quickly as possible.





Start Learning »

vmware



ServerWare®/Supermicro in Partnership with Intel offers a total solution for Lustre on ZFS with Supermicro’s industry leading hardware, software and services infrastructure. The evolution of software defined high availability platforms like ZFS running on Linux now make it possible to meet the performance requirements of HPC on open industry standard x86 platforms, reducing storage costs by up to 90%





Start Learning »

Lustre



ServerWare®/Supermicro’s SuperStorage Bridge Bay running Windows Storage Server 2012 R2 Standard is a fully redundant, fault-tolerant Cluster-in-a-Box designed to provide mission-critical availability for SMB/ROBO applications





Start Learning »

Microsoft



ServerWare®/Based on proven IBM XIV® technology and the Supermicro industry leading Super Storage Server, the Supermicro Hyperconverged appliance with IBM Spectrum Accelerate delivers combined compute ,storage and networking with predictable, consistent block storage performance, management scaling up to 144 nodes managed from a single console, and a rich feature set that includes remote mirroring and granular multi-tenancy





Start Learning »

IBM Spectrum Accelerate™





Hadoop Solutions
Utilizing big data analytics is no longer a question of when, but how. Enterprises deploying Hadoop solutions need a high performance, scalable and reliable infrastructure and can expend a large amount of resource searching for the best architecture and the most capable solution provider. The Supermicro Hadoop Solutions are certified server, storage, networking, software and service configurations that take the guess work out of designing and deploying a truly scalable Big Data infrastructure.


Supermicro Hadoop Cluster Solution

(Up to 1.15 PB Storage and 9 TB Memory)

Key Benefits
Designed ground up

with optimal server and cluster configurations

Best price/performance

and price/capacity with industry leading server and storage platforms

Advanced architecture

based on the latest technologies, e.g. Xeon E5-2600 v3, SAS3, NVMe

hadoop1



Includes full cluster customization, burn-in and testing, BIOS and Firmware updates, network configurations, pre-install of the Hadoop distributions of choice, including Cloudera and Hortonworks.



Supermicro Hadoop Cluster Solution Offerings
7 Different customized cluster configurations to deliver optimized performance for your Big Data Solution:
• PoC Cluster
• High Capacity Cluster
• IO Optimized Cluster
• High Density Compute Cluster
• Large Memory & Storage Cluster
• Balanced Cluster
• Large Memory Cluster


Hadoop Cluster Technical Specifications
PoC Cluster High Capacity Cluster IO Optimized Cluster High Density Compute Cluster Large Memory and Storage Cluster Balanced Cluster Large Memory/Dual 10G Cluster
Model / SKU SRS-14TP08-HADP-01 SRS-42SG18-HADP-01 SRS-42SG18-HADP-02 SRS-42FT36-HADP-01 SRS-42FT36-HADP-02 SRS-42TP36-HADP-01 SRS-42TP34-HADP-02
Data Node 8 18 18 36 36 36 34
Form Factor 2U TwinPro 2U SSG 4U FatTwin 2U TwinPro
2x
E5-2630 v3
2x
E5-2630 v3
2x
E5-2650 v3
2x
E5-2680 v3
2x
E5-2650 v3
2x
E5-2630 v3
2x
E5-2650 v3
64GB 64GB 128GB 128GB 256GB 64GB 256GB
6x 3.5″ Bays 16x 3.5″ Bays 24x 2.5″ Bays 8x 3.5″ Bays 8x 3.5″ Bays 6x 3.5″ Bays 12x 2.5″ Bays
Total Data Drive 48 288 432 288 288 216 408
Total Cores 128 288 360 864 720 576 680
Total Memory 512GB 1152GB 304GB 4608GB 9216GB 2304GB 8704GB
Total Storage 96TB (2TB) 1.15PB (4TB) 432TB (1TB) 576TB (2TB) 1.15PB (4TB) 432TB (2TB) 408TB (1TB)
Name Node 2x 1U WIO 3x 1U WIO 3x 1U WIO 3x 1U WIO 3x 1U WIO 3x 1U WIO 3x 1U WIO
Management Node 1x 1U WIO 1x 1U WIO 1x 1U WIO 1x 1U WIO 1x 1U WIO 1x 1U WIO 1x 1U WIO
Switches 1x 24PT GbE 1x 48PT GbE 1x 48PT GbE 1x 48PT GbE

1x 48PT 10GBase-T

1x 48PT10G SFP+

2x 48PT 10G SFP+

Cabinet (WxHxD) 14U
21.6×30.6×37.4
42U
23.5x 82.4x 48
PDU 1x2U 30A 2x 50A 208 3-Phase Metered PDU
208V Switched Single-Phase

Virtual SAN Ready System

All-Flash Supermicro Virtual SAN Ready Nodes

80Plus Platinum
SYS-F628R3-RTB+
• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 6 + 2 Hot-swap 3.5″ SATA3 HDD Bays
• 16x DIMM slots; up to 1TB DDR4 2133MHz reg. ECC memory
• 1x PCI-E 3.0 x16, 1x PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• I/O ports: 2x GbE, 1x Video, 1x COM, 2x USB 3.0
80Plus Platinum • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 2x 8cm 11K RPM middle fans
• 1280W Redundant Platinum Level Power Supplies
TwinPro
Titanium, 96% Efficiency
Power Supplies
Titanium Level
SYS-6028TP-DNCR
• 2x DP nodes in 2U; depth 30.5″, Each Node (x2 nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 1x PCI-E 3.0 x16 and 1x PCI-E x8 slots
• 6x 3.5″ Hot-swap Drive Bays (up to 4x NVMe + 2x SAS3 or 6x SAS3)
• I/O ports: 2x GbE, 1x Video, 2x USB 3.0
Titanium Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 4x 80mm heavy duty fans w/ optimal fan speed control
• 1600W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies
TwinPro
80Plus Platinum
SYS-2028TP-DC1R
• 2x DP nodes in 2U; depth 28.5″, Each Node (x2 nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 1x PCI-E 3.0 x16 slot and 1x PCI-E x8 slot
• 1x PCI-E 3.0 x16, 1x PCI-E x8, and GPU support via x16 slot
• 12x 2.5″ Hot-swap SAS (8) / SATA (4) Drive Bays
• 1x InfiniBand port (FDR, 56Gbps), w/ QSFP connector
• I/O ports: 2x GbE, 1x Video, 2x USB 3.0
Platinum Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 4x 80mm heavy duty fans w/ optimal fan speed control
• 1280W Redundant Platinum Level Digital Power Supplies

Titanium, 96% Efficiency
Power Supplies
Titanium Level
SSG-6028R-E1CR16T
• 2U Storage Server – Expansion / Performance / Flexibility
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 16x 3.5″ Hot-swap SAS3 Drive Bays (SAS3 via LSI 3108)
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 1x PCI-E 3.0 x16 and 6x PCI-E 3.0 x8 slots
• I/O ports: 2x 10GBase-T, 1x Video, 1x COM, 2x USB 3.0, 1x Type A
Titanium Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 4x 80mm hot-swap redundant PWM cooling fans
• 1000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies

Titanium, 96% Efficiency
Power Supplies
Titanium Level
SYS-6028U-E1CNR4T+ / SYS-6028U-E1CNRT+
• Virtualization Hosting, Cloud Computing, Data Center
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 12x 3.5″ Hot-swap SAS3 via Expander and AOC; 4x NVMe
• 24x DIMM slots; up to 1.5TB DDR4 2133MHz ECC memory
• SYS-6028U-TNRT+: 7x PCI-E 3.0 x8 slots (5 FH, 2 LP)
SYS-6028U-TNR4T+: 6x PCI-E 3.0 x8 slots (4 FH, 2 LP)
• I/O ports: 4x 10GBase-T (-E1CNR4T+) / 2x 10GBase-T (-E1CNRT+),
1x Video, 1x COM/Serial, 5x USB 3.0
Titanium Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 4x heavy duty fans w/ optimal fan speed control
• 1000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies

80Plus Platinum
SSG-6028R-E1CR12L
• 2U Storage Server – Expansion / Performance / Flexibility
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 12x 3.5″ Hot-swap SAS3/SATA3 drive bays,
2x 2.5″ optional Hot-swap Drive Bays (rear)
SAS3 via LSI 3008 controller, IT mode
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 1x PCI-E 3.0 x16, 6x PCI-E 3.0 x8 (slot 1 & 2 occupied)
• I/O ports: 2x 10GBase-T, 1x Video, 1x COM, 2x USB 3.0, 1x Type A
Platinum Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3x heavy duty fans w/ optimal fan speed control
• 920W Redundant Platinum Level Power Supplies

80Plus Platinum
SSG-2028R-E1CR24L
• 2U Storage Server – Expansion / Performance / Flexibility
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 24x 2.5″ Hot-swap SAS3/SATA3 drive bays; 2x 2.5″ optional Hot-swap rear side drive bays
• SAS3 via LSI 3008 – IT mode; SW RAID
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 1x PCI-E 3.0 x16, 6x PCI-E 3.0 x8 (slot 1 & 2 occupied)
• I/O ports: 2x 10GBase-T, 1x Video, 1x COM, 2x USB 3.0, 1x Type A
Platinum Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3x heavy duty fans w/ optimal fan speed control
• 920W Redundant Platinum Level Power Supplies

80Plus Platinum
SYS-1028R-WC1R
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 10x 2.5″ Hot-swap SAS/SATA Drive Bays; optional 2x 2.5″ NVMe drives supported
• 16x DIMM slots; up to 1TB DDR4 2133MHz ECC memory
• 2x PCI-E 3.0 x16 FHHL slots
• I/O ports: 2x GbE, 2x SuperDOM, 1x Video, 1x COM, 6x USB 3.0 (4 rear, 2 front)
Platinum Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 5x 4cm Counter-rotating PWM fans
• 700W Redundant Platinum Level Power Supplies

80Plus Platinum
SYS-1018R-WC0R
• Single Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s
• 8x 2.5″ Hot-swap SAS3/SATA3 + 2x 2.5″ Hot-swap SATA3 Drive Bays; default support 8+2 SATA3 HDD
• 8x DIMM slots; up to 512GB DDR4 2133MHz ECC memory
• 2x PCI-E 3.0 x16 FH slots and 1x PCI-E 3.0 x8 (in x16) HH slot
• I/O ports: 2x GbE, 2x SuperDOM, 1x Video, 2x COM, 2x USB 3.0, 4x USB 2.0
Platinum Level • System management: Built-in Server management tool
(IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3x PWM Cooling fans
• 750W Redundant Platinum Level Power Supplies

1Gb & 10Gb Ethernet Switches
• Layer 2/3 Ethernet Switching, link aggregation (LACP), Jumbo frames, VLAN support
• Configuration Flexibility:
SSE-G24-TG4 – 24 ports of RJ45 1Gbps Ethernet with 4 SFP Combo ports,
4 ports 10Gbps Ethernet (CX4, XFP, or SFP+), Stacking
SSE-G48-TG4 – 48 ports of RJ45 1Gbps Ethernet with 4 SFP Combo ports,
4 ports 10Gbps Ethernet (CX4, XFP, or SFP+), Stacking
SSE-X24S / SSE-X3348S(R) – 24 ports 10Gbps Ethernet (SFP+), Reverse airflow option
• Management: Web-based management interface, Industry standard CLI with telnet
SSH or local management port, Scripting, Logging
• Routing, Multicast:
Quality of service and DiffServ – 8 priority queues per port; Adjusted WRR and Strict Priority Scheduling
Security – 802.1x port based authentication, RADIUS and TACACS+ authentication, SSH / SSL encryption
• Dimensions: 17.3″W x 15.2″D x 1.7″H (440mm x 386mm x 43mm)


IPMI Server Management
• HW fault alerts – E-mail or SNMP
• Redundant access for management
• Support for open standards (SMASH 2.0, LDAP, WSMAN)
• VLAN support
• KVM and Virtual Media and SOL (no additional license needed)
• Easy maintenance (Command line flash tools for firmware update)

The ServerWare® Events

Using Cache For Your Solutions and Why.

Watch the downloads on Intel® Cache Acceleration Software
